Wheel System, Traction 197Service Manual – SC6500
™
Troubleshooting Chart
Flash
Code
#
Programmer LCD
Display/ Effect Of Fault
Possible Cause(s) Set/Clear Conditions
68 VCL (Vehicle Control
Language) Run Time
Error
ShutdownMotor;
ShutdownMainContactor;
ShutdownEMBrake;
ShutdownThrottle;
ShutdownInterlock;
ShutdownDriver1;
ShutdownDriver2;
ShutdownDriver3;
ShutdownDriver4;
ShutdownPD; FullBrake;
ShutdownPump.
1. VCL code encountered a
runtime VCL error.
2. See Monitor menu » Controller:
VCL Error Module and VCL
Error. This error can then be
compared to the runtime VCL
module ID and error code
denitions found in the specic
OS system information le.
Set: Runtime VCL code error
condition.
Clear: Edit VCL application
software to x this error
condition; ash the new
compiled software and
matching parameter defaults;
cycle KSI.
69 External Supply Out of
Range
None, unless a fault action is
programmed in VCL.
1. External load on the 5V and
12V supplies draws either too
much or too little current.
2. Fault Checking Menu
parameters Ext Supply Max
and Ext Supply Min are mis-
tuned.
3. See Monitor menu » Outputs:
Ext Supply Current.
Set: The external supply
current (combined current
used by the 5V supply [pin 26]
and 12V supply [pin 25]) is
either greater than the upper
current threshold or than
the lower current threshold.
The thresholds are dened
by the External Supply Max
and External Supply Min
parameter settings.
Clear: Bring the external
supply current within range.
71 OS General
ShutdownMotor;
ShutdownMainContactor;
ShutdownEMBrake;
ShutdownThrottle;
ShutdownInterlock;
ShutdownDriver1;
ShutdownDriver2;
ShutdownDriver3;
ShutdownDriver4;
ShutdownPD; FullBrake;
ShutdownPump.
1. Internal controller fault.
Set: Internal controller fault
detected.
Clear: Cycle KSI.
72 PDO Timeout
ShutdownInterlock; CAN
NMT State set to Pre-
operational.
1. Time between CAN PDO
messages received exceeded
the PDO Timeout Period.
Set: Time between CAN PDO
messages received exceeded the
PDO Timeout Period.
Clear: Cycle KSI or receive
CAN NMT message.
