Noble UH30-E - UH30-E-SEER Operating Parameters

5
07610-004-45-09-D
UH30-E-SEER
Operating Capacity:
Racks per Hour 20
Dishes per Hour 500
Glasses per Hour 720
Tank Capacity (Gallons):
Wash Tank 3
Rinse Tank 1.66
Always refer to the machine data plate for specic electrical and water
requirements. The material provided on this page is for reference only and
is subject to change without notice.
Water Temperatures (°F):
Minimum Wash Temperature 155
Minimum Rinse Temperature 180
Minimum Incoming Water Temperature 40
Maximum Incoming Water Temperature 90
Other Water Requirements:
Water Flow Pressure (PSI) 10
Flow Rate Minimum (GPM) 5.16
Water Line Size (NPT) 3/4" Male GHT
Connect to true 1/2" ID Line
Drain Line Size (NPT) 1" ID
1 3/8" OD
Connect to MIN 1 1/2" Drain with
Air-gap
NOTICE
i
UH30-E-SEER OPERATING PARAME-
SPECIFICATIONS
Incoming water is from a
"cold" water line.
