07610-004-45-09-D
34
UH30-E-SEER ELECTRICAL PANEL, 208/230 V
PARTS
ITEM QTY DESCRIPTION PART NUMBER
Complete UH30-E-SEER Electrical Panel Assembly,
208/230 V
05700-004-51-91
1 1 Electrical Panel 05700-004-40-63
2 1 PCB, Electronic Control 05945-004-36-34
3 3 Contactor, 208/230 V 05945-002-74-20
4 1 Terminal Board 05940-002-78-97
5 1 Terminal Board 05940-004-21-34
6 2 Relay 05945-111-89-75
7 18 Fastener 05340-111-58-10
8 5 Nut, Plated 05340-118-04-00
9 3 Screw, 10-32 x 1” 05305-002-19-42
10 15 Screw, 10-32 x 5/8" 05305-003-02-12
11 5 Screw, 6-32 x 3/8” 05305-002-25-91
12 1 Resistor, Wire Wound Power, 1/4" Tabs 05935-004-44-44
13 1 Dinrail, 2” 05700-002-36-09
