07610-004-45-09-D
32
UH30-E ELECTRICAL PANEL, 208/230 V
PARTS
ITEM QTY DESCRIPTION PART NUMBER
Complete UH30-E Electrical Panel Assembly, 208/230 V 05700-004-42-07
1 1 Electrical Panel 05700-004-40-63
2 3 Contactor, 208/230 V 05945-002-74-20
3 13 Screw, 10-32 x 5/8" 05305-003-02-12
4 3 Screw, 10-32 x 1” 05305-002-19-42
5 1 PCB, Electronic Control 05945-004-36-34
6 1 Terminal Board 05940-004-21-34
7 1 Terminal Board 05940-002-78-97
8 1 Relay 05945-111-89-75
9 5 Screw, 6-32 x 3/8” 05305-002-25-91
10 1 Bracket, Resistor Mount 05700-004-44-51
11 1 Resistor, Wire Wound Power, 1/4" Tabs 05935-004-44-44
1
2 3
4 5
6
7
891011
