Noble UH30-E - Product Specifications; UH30-E;UH30-E-SEER Dimensions

07610-004-45-09-D
2
SPECIFICATIONS
UH30-E DIMENSIONS
1/4
[7 mm]
26
[660 mm]
3 1/2
[88 mm]
24 1/4
[615 mm]
3 3/8
[87 mm]
9 3/4
[246 mm]
8
[202 mm]
BC
A
D
BACK
SIDEFRONT
TOP
B
C
A
D
14 1/4
[363 mm]
7 1/2
[190 mm]
3 7/8
[99 mm]
6 5/8
[169 mm]
3
[76 mm]
42 3/4
[1087 mm]
16 3/4
[426 mm]
DOOR OPEN
33 5/16
[846 mm]
14 1/4
[362 mm]
CLEARANCE
LEGEND
A - Electrical Connection
B - Water Inlet (with 6' Hose)
(3/4" Male GHT, connect to true
1/2" ID line, 40-90 °F)
C - Drain Connection
(1" ID, 1 3/8" OD)
(Connect to MIN 1 1/2" Drain with Air-gap)
D - Chemical Port
All dimensions from the floor can be increased 1” using the machine’s adjustable feet.
LEGEND
A - Electrical Connection
B - Water Inlet (with 6' Hose)
(3/4" Male GHT, connect to true
1/2" ID line, 40-90 °F)
All dimensions from the oor can be increased 1" using the machine's adjustable feet.
C - Drain Connection
(1" ID, 1 3/8" OD)
(Connect to MIN 1 1/2" Drain with Air-gap)
D - Chemical Port
