39
07610-004-45-09-D
DOOR
PARTS
ITEM QTY DESCRIPTION PART NUMBER
1 1 Outer Door Weldment 05700-004-52-86
2 2 Screw, 10-32 x 1/4" 05305-173-01-00
3 2 Bolt, 1/4-20 x 3/8" Hex 05305-274-20-00
4 2 Washer, 1/4-20 ID 05311-174-01-00
5 1 Gasket, Door 20" 05330-003-58-35
6 2 Gasket, Door 17 1/8" 05330-003-58-36
7 12 Fastener, 10-32 05340-111-58-10
8 1 Door Handle 05700-003-26-62
9 2 Stop, Door Hinge 05700-003-32-55
10 1 Hinge, Left 05700-003-32-71
11 1 Hinge, Right 05700-003-32-72
12 1 Inner Door 05700-003-33-21
13 1 Baffle, Door 05700-003-33-38
14 2 Hinge Spacer 05700-003-33-42
15 1 Switch Assembly 05700-003-34-80
16 2 Retaining Plate 05700-011-44-37
17 1 Channel, Door Seal 05700-003-55-49
18 6 Screw, 1/4-20 x 1 1/2" Hex Head 05305-274-23-00
19 1 Gasket, Door L 05330-004-36-05
20 1 Gasket Clamp 05700-004-36-56
21 6 Pop Rivet, 1/8" x 3/8" 05320-003-06-98
22 12 Screw, 10-32 x 1/2" with Washer 05305-002-32-37
23 1 Bracket, Door Magnet 05700-004-52-73
