SEER SYSTEM
PARTS
ITEM QTY DESCRIPTION PART NUMBER
1 1 Heat Exchanger, 3/8", Tubes 1/2" 04420-004-37-32
2 1 SEER System, Top Cover 05700-004-47-21
3 1 SEER System, Bottom Cover 05700-004-47-19
4 36 Locknut, 1/4-20 Hex with Nylon Insert 05310-374-01-00
5 1 SEER System, Plumbing 05330-004-55-58
6 1 SEER System, Top Gasket 05330-004-48-50
7 1 SEER System, Bottom Gasket 05330-004-48-51
8 1 SEER System, Diversion Plate 05700-004-47-27
9 1 SEER System, Plumbing Seal Bracket 05700-004-47-30
10
10a
10b
10c
10d
10e
10f
10g
10h
10i
1
4
1
1
1
1
1
1
1
2
Complete Fan & Housing Assembly, 208/230 V
Complete Fan & Housing Assembly, 115 V (for 460 V Machine)
Locknut, 1/4-20 Hex with Nylon Insert
Bushing & Housing Assembly
Bracket, Interchangeable Bearing Boot
Gasket, Interchangeable Bearing Boot
Wheel, Blower
Gasket, Motor
Bracket, Motor Adjustment
Motor, Fan, 208/230 V
Motor, Fan, 115 V (for 460 V Machine)
Screw, 6-32 x 1 3/4"
05700-004-50-83
05700-004-52-63
05310-374-01-00
03120-004-50-88
05700-004-50-94
05330-004-50-95
05999-004-50-85
05330-004-50-90
05700-004-50-92
05999-004-50-84
05999-004-52-62
05305-004-36-67
11 1 SEER System, Plumbing Seal Gasket (Outlet) 05330-004-55-57
12 1 SEER System, Plumbing Seal Bracket (Outlet) 05330-004-51-27
13 1 SEER System, Gasket Top 05330-004-55-54
14 5 Washer, Bonded Sealing 1/4" x 3/4" OD 05311-002-77-79
15 1 Strip, 1/2" x 1/8” x 22" Sponge Rubber 05330-100-10-00
16 2 Tie, Panduit Cable 05975-602-01-16
17 1 Adapter, Double Male 04720-004-51-55
18 1 Elbow, 90-degree 1/2" Street Brass 04730-206-08-00
19 20 Washer, 1/4-20 ID 05311-174-01-00
20 1 SEER System, Bottom Mount 05700-004-47-22
21 1 Gasket, Enclosure Back 05330-004-56-02
22 1 Bracket, Bearing Hard Stop 05700-004-67-53
23 1 Discharge Hose, Rinse Tank 05700-004-51-56
24 1 Nipple, 1/2" Close Brass 04730-207-15-00
25 1 Tee, 1/2" Brass 04730-211-27-00
26 1 SEER System, Shock Absorber (Water Hammer) 04730-004-58-56
