7210 SAS-M CHASSIS INSTALLATION GUIDE System Overview
Issue: 07 3HE 10089 AAAA TQZZA Edition 01 15
Figure 2 7210 SAS-M 24F 2XFP (ETR) Front Panel
The 7210 SAS-M 24F 2XFP and 7210 SAS-M 24F 2XFP ETR include the following
features:
• 24 100/1000 SFP ports and two 10G XFP ports
• one RJ-45 management port for firmware upgrade or system management
• one RJ-45 console (RS-232 interface) connector for device management
• 7210 SAS-M 24F 2XFP ETR version supports extended temperature range
• embedded SR OS
• compact size: 1.5 RU height, 19 in. (48.26 cm) rack-mountable metal
enclosure, 10 in. (25.4 cm) depth (ETSI)
Crit
SR72029
Note: Except for the labeling, the 7210 SAS-M 24F 2XFP and 7210 SAS-M 24F 2XFP ETR
chassis are identical in terms of front panel appearance.
