Configuring the System
62
7210 SAS-M CHASSIS INSTALLATION GUIDE
3HE 10089 AAAA TQZZA Edition 01 Issue: 07
Do you want to overwrite cf1:/bof.cfg with the new settings? (yes/no): yes
Type yes and press <Enter>.
The 7210 SAS-M should boot now.
Successfully saved the new settings in cf1:/bof.cfg
Configuring Network with eth-mgmt Port Setting.....
No existing config file URL
Primary image location: ftp://*:*@10.10.170.22/./images/both.tim
Loading image ftp://*:*@10.10.170.22/./images/stu-hw/both.tim
Version B-2.0.B1-57, Tue Jul 13 23:24:58 IST 2010 by builder in /builder/2.0B1/panos/
main
text:(24285906-->114984824) + data:(2989128-->18305224)
Executing TiMOS image at 0x100000
.........
After the 7210 SAS-M boots up, you should see the following prompt:
All rights reserved. All use subject to applicable license agreements.
Built on Tue Jul 13 23:24:58 IST 2010 by builder in /builder/2.0B1/panos/main
Login:
Both the default username and password are admin. Use it to log in to the device.
5.2.1.4 Downloading the TiMOS Software to the Internal Flash
If you want to boot the 7210 SAS-M from the internal flash, you will have to copy the
image there.
If you have used the uplinkA or uplinkB port to boot the 7210 SAS-M, use any of the
network ports for IP connectivity and follow the procedure given below to configure
an IP interface and a route.
If you have used the out-of-band Ethernet management port, then you do not need
to configure the IP interface. Skip to the step "Check IP connectivity" below and
continue from there.
Note: The status LED will be green when the device has successfully completed the boot
process and is running normally. It is highly recommended that you change the default
admin password to prevent unauthorized access to the node.
