7210 SAS-M CHASSIS INSTALLATION GUIDE Configuring the System
Issue: 07 3HE 10089 AAAA TQZZA Edition 01 51
5.2 Initializing the System and Downloading
Software
The 7210 SAS-M ships with bootloader and TiMOS on the compact flash memory
device. When the system is powered up for the first time, the bootloader will attempt
an auto-init procedure (see the System Basics Guide for more information).
However, the auto-init can be interrupted and the boot operation controlled manually.
5.2.1 Booting in the Lab
There are several ways to boot the 7210 SAS-M from the network. You can choose
to boot the device using one of the following options:
• Using the image shipped along with the 7210 SAS-M to boot the device
• Using the network to load the image and boot the device
The following sections describe how to boot the device using either of the options
listed above.
Figure 15 7210 SAS-M Boot Process
Note: By default, 7210 SAS platforms attempt the autoinit procedure unless interrupted by
user and forced to use TiMOS available in the flash.
OSSG325
FTP
Server
IP Address:
10.10.170.22/24
Port: 24
IP Address: 10.135.4.172/24
Gateway: 10.135.4.1
Console Cable
SAS-M
To Next Page
