Nordson MEG II User Manual

1606179-01
©2007 Nordson Corporation
For parts and technical support call (800) 433-9319.
Refer to the MEG II Spray Gun manual 334669 for complete service and parts information.
A - Soft Goods Kit 343989
B - PTFE Seat O-ring Kit 1073596
A
A
A
A
A
A
A, B
A
Effective Manual Rev. H
®
MEG II Spray Gun
C - Armature Spring Kit 1606337
D - Gun Module Kit
F - Coil Kit 343993
E - Ball and Seat Kit
C
C
C
Extended Tip:
1075291
Extended Tip:
1076115
Reduced
Cavity:
1062095
Reduced
Cavity:
1062094
C
Issued 9/14
