Network Configuration
You can use BayStack 410-24T switches to connect workstations, personal
computers (PCs), and servers to each other by connecting these devices directly to
the switch, through a shared media hub that is connected to the switch, or by
creating a virtual LAN (VLAN) through the switch.
This section provides four network configuration examples using BayStack
410-24T switches:
• Desktop switch application
• Segment switch application
• High-density switched workgroup application
• Fail-safe stack application
Desktop Switch Application
Figure 1-6 shows the BayStack 410-24T switch used as a desktop switch, where
desktop workstations are connected directly to switch ports.
This configuration uses the optional 400-4TX MDA (10BASE-T/100BASE-TX)
and provides dedicated 100 Mb/s connections to the network center, to the server,
and for two users. Twenty-four users are provided with dedicated 10 Mb/s
connections.
