Introduction to the BayStack 410-24T Switch
309985-B Rev 00
1-67
Trunk Configuration Screen for Switch S2
As shown in Figure 1-40
on page 1-63, switch S2 is set up with two trunk
configurations (T2 and T3). Both trunks connect directly to switch S1. As in the
previous screen examples, to set up a trunk configuration choose MultiLink Trunk
Configuration from the MultiLink Trunk Configuration Menu screen.
Figure 1-43
shows the MultiLink Trunk Configuration screen for switch S2.
Figure 1-43. MultiLink Trunk Configuration Screen for Switch S2
Switch S2 is configured as follows:
• Trunk (read only) indicates the trunks (1 to 6) that corresponds to the switch
ports specified in the Trunk Members fields.
• Trunk Members (Unit/Port) indicates the ports that can be configured, in
each row, to create the corresponding trunk:
-- Ports 25 and 26 are assigned as trunk members of trunk 1.
-- Ports 1 and 3 are assigned as trunk members of trunk 2.
MultiLink Trunk Configuration
Trunk Trunk Members (Unit/Port) STP Learning Trunk Mode Trunk Status
----- ------------------------------- ------------ --------------- ------------
1 [ /25 ][ /26 ][ / ][ / ] [ Normal ] Basic [ Enabled ]
2 [ /1 ][ /3 ][ / ][ / ] [ Normal ] Basic [ Enabled ]
3 [ / ][ / ][ / ][ / ] [ Normal ] Basic [ Disabled ]
4 [ / ][ / ][ / ][ / ] [ Normal ] Basic [ Disabled ]
5 [ / ][ / ][ / ][ / ] [ Normal ] Basic [ Disabled ]
6 [ / ][ / ][ / ][ / ] [ Normal ] Basic [ Disabled ]
Trunk Trunk Name
----- ------------------
1 [ S2:T2 to S1 ]
2 [ S2:T3 to S1 ]
3 [ Trunk #3 ]
4 [ Trunk #4 ]
5 [ Trunk #5 ]
6 [ Trunk #6 ]
Enter text, press <Return> or <Enter> when complete.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
