297-1001-330 Standard 11.04 June 1998
Section
PROVSERV
Description
CCS7 STP gateway screening failures
Definition
C7GTWERR provides information on the number of message signal units
(MSUs) that caused errors in the screening function. In this case, the MSUs
that were to be blocked by the screening process went through to the LIU7
peripherals.
Measurement list
C7GTWERR uses measurement MSUSCRER of OM group C7GTWSCR.
Normalizer
C7GTWERR is normalized by the total number of MSUs received and
transmitted. The affected fields are C7MSUTX, C7MSUTX2, C7MSURX,
and C7MSURX2 of OM group C7LINK2.
Diagnostics
Verify OM group C7GTWSCR, field MSUSCRER. See log CCS503 for
further information. Review datafill for tables C7GTWLKS, C7ALWOPC,
C7BLKOPC, C7ALWDPC, C7BLKDPC, C7ALWSIO, C7DSTFLD,
C7CGPA, C7ALWGTT, C7CDPA, and C7AFTPC.
5-44 SPMS SERVICE index descriptions 5-445-44
Basic index C7GTWERR
