PIC Statement BACnet Protocol Implementation Conformance Statement (Normative)
44 BACnet Gateway-3 Installation and Operation Manual - P/N: 53372:Rev: A 5/6/09
Supported - Binary Output
Present Value BACnet Enumeration BACnetLifeSafetyState NFN State
0 IssQuiet Normal
1 IssPreAlarm PreAlarm
2 IssAlarm Fire Alarm, Security Alarm (Life/Property), Critical Process Alarm
(Life/Property), Medical Emergency
3 IssFault Security Trouble, Fire Trouble, Non-Fire Trouble, Fire Device or Zone
Disabled, Non-Fire D evice D isab led
7 IssActive Non-Fire Activation
22 IssSupervisory Supervisory (Equipment), Supervisory (Guard’s Tour)
Tracking Value BACnet Enumeration BACnetLifeSafetyState NFN State
0 IssQuiet Normal
1 IssPreAlarm PreAlarm
2 IssAlarm Fire Alarm, Security Alarm (Life/Property), Critical Process Alarm
(Life/Property), Medical Emergency
3 IssFault Security Trouble, Fire Trouble, Non-Fire Trouble, Fire Device or Zone
Disabled, Non-Fire D evice D isab led
7 IssActive Non-Fire Activation
22 IssSupervisory Supervisory (Equipment), Supervisory (Guard’s Tour)
Event State BACnet Enumeration BACnetEventState NFN State
0 EsNormal Normal
1 EsFault Security Trouble, Fire Trouble, Non-Fire Trouble, Fire Device or Zone
Disabled, Non-Fire D evice D isab led
2 EsOffNormal All statuses other than normal and fault.
Reliability BACnet Enumeration BACnetReliability NFN State
0 reNoFaultDetected All statuses other than trouble.
7 re_UnreliableO ther Security Trouble, Fire Trouble, Non-Fire Trouble
Mode BACnet Enumeration BACnetMode NFN State
0 IsmOff Power-Up State
10 IsmEnabled Set if point has been disabled and subsequently enabled since startup.
11 IsmDisabled Fire Device or Zo ne D isab led, Non-Fire Device Disabled
Silence State BACnet Enumeration NFN State
0 ssUnsilenced Audibles Unsilenced
1 ssA udiblesS ilenced Audibles Silenced
Operation
Expected
BACnet Enumeration NFN State
0 NA
Maintenance
Required
BACnet Enumeration NFN State
NA NA NA
Event Enable BACnet Event Transition Bit
toOffNormal
toFault
Direct Reading
REAL NA % Alarm
Status Flags
Boolean BACnet Status Flags NFN State
0,0,0,0
Normal
1,0,0,0 InAlarm
Fire Alarm, Security Alarm (Life/Property), Critical Process Alarm
(Life/Property), Medical Emergen, PreAlarm
1,1,0,0 InAlarm, Fault
Security Trouble, Fire Trouble, Non-Fire Trouble
1,0,0,1 InAlarm, OutOfService
Fire Device or Zo ne D isab led, Non-Fire Device Disabled
Out of Service
Boolean NFN State
0 FALSE
All statuses other than disable
1TRUE
Fire Device or Zo ne D isab led, Non-Fire Device Disabled
