11
128-0521-002
2. Install Beam member between Stands (Figure above) and tighten the Bolts against beam mounting surface.
3. Position Tray onto Beam and secure with screws and washers
(Figure above) using 6mm Allen key.
4. * Optional additional weight (Quartz sand) in the stabilizing
beam, not included. (Figure right)
ASSEMBLY NOTE
Washer Tray
Spring
Bolt
Repeat for all 4 bolt holes on Beam
ASSEMBLY NOTE
Washer
Spring
Bolt
Repeat for all 8 bolt holes on Stand
Additional Weight
Quartz Sand
To Next Page
