11. NOVA Nebula Lathe Parts List
ITEM
NO.
DESCRIPTION SKU QTY.
1 Headstock Assembly 5569002
1.1 Nebula Headstock casting 5569011 1
1.2 120mm Stator 5569038 1
1.3 Control Board Assembly 55530 1
1.4 Rotor Assembly 5569007 1
1.5 Index Pin Assembly 5569009 1
1.6 Front Bearing 6210 VV
1
1.7 ASR Locking Collar* 5569039 1
1.8 Nebula faceplate ASR M33x 3.5* 5569033 1
1.9 External Circlip 35mm EC35 1
1.10 Internal Circlip 75mm IC75 2
1.11 Rear Bearing 6207 VV 1
1.12 Casted Bearing Housing 55146 1
1.13 Optical Position Sensor 55020 1
1.14 6mm Dowel Pins 55055 2
1.15 Optical Sensor Mounting Screw MPB0412 2
1.16 Metal Cover Plate 55174 1
1.17 Rotor Assembly Mounting Bolt C06020 8
1.18 Indexed Fan 55011 1
1.19 Index Fan Key 55051 1
1.20 Index Wheel Set Screw M5x6 SZ0506 3
1.21 Headstock Handwheel 5569016 1
1.22 Handwheel Set Screw M5x8 SZ0508 1
1.23 Headstock Locking Shaft 5569018 1
1.24 Locking Handle End Cap 5569028 1
1.25 Handle Grip 5569029 1
1.26 Locking Handle 5569030 1
1.27 Locking Handle set screw M8x8 SZ0808 1
1.28 Locking Shaft Set screw M6x 20 SZ0620 1
1.29 Headstock Locking Boss 5569019 1
1.30
Main control Board mounting
screw M6x13
MPB0613 4
1.31 Name Plate 5569037 1
1.32
Name Plate Rivet 4x10 or Screw
M4x8
RV0410 or
MPB0408
4
1.33 Panel mounting screw M6x6 MPB0606 6
1.34 Dowel Pin Ø4 x 20 23043 2
NP Optical Sensor Cable 55411 1
2A Rear cover plate assembly 230V 5569008-A
2.1 Headstock Back Cover Plate 5569027-A 1
2.2 Main Power Module 5699044 1
2.3 Thermal Breaker 5699045 1
2.4
Plastic Rivets for EMI Filter [Only
for 220-240V Markets]
RV0405 2
2.5
EMI filter [Only for 220-240V
Markets]
55236 1
2.6 Cover Plate Mounting Screws MPB0410 8
2.7
Cable with Gland (EU) 55106
1 Cable with Gland (AU/NZ) 55090
Cable with Gland (UK) 55112
2B Rear cover plate assembly 110V 5569008-B
2.8 Headstock Back Cover Plate 5569027-B 1
2.9 Thermal Breaker 5699045 1
2.10 Cover Plate Mounting Screws MPB0410 8
2.11 Fuse holder included Fuse 55404/55229 1
2.12 Rocker Switch 5569071 1
2.13 Cable with Gland (USA) 55062 1
ITEM
NO.
DESCRIPTION SKU QTY.
3 HMI Assembly 5699005
3.1 HMI Panel Body-Plastic 5698000 1
3.2 HMI Keypad Layer 5699030 1
3.3 HMI Circuit Board 55446 1
3.4 Knob Cap 5699034 1
3.5 Emergency Stop Switch 5699016 1
3.6 HMI board screw M3x10 MPB0310 4
NP HMI 10 Pin Cable 55139 1
4 Tailstock Assembly 5569003
4.1 Tailstock Casting 5569012 1
4.2 Tailstock Quill 5569020 1
4.3 Tailstock Quill Lead Screw 5569021 1
4.4 Tailstock Handwheel 5569022 1
4.5 Tailstock Handwheel Handle 5699028 1
4.6
Tailstock Handwheel Handle
Stud Bolt
5699046 1
4.7 Quill locking handle 5569040 1
4.8 Quill Alignment screw SZ0820 1
4.9 Alignment screw sleeve 5569068 1
4.10 Tailstock lock Camshaft 5569023 1
4.11 Camshaft End Cap 5569028 1
4.12 Camshaft Grip 5569029 1
4.13 Handle stopper 5569024 1
4.14
Tailstock Handwheel Locking
Nut
LN25 1
4.15
Tailstock Alignment Plate
Screw
BHC0816 4
4.16
Tailstock Alignment Screw
Washer
FW08 4
4.17 Tailstock tool Bracket 5569031 2
4.18
Bracket mounting screw
M5x10
MPB0510 2
4.19 Door knob screw M5 x 6 MPB0506 1
4.20 Rubber Buffer screw M3 x 10 MPB0310 1
4.21 Tailstock Metal Plate 5569026 1
4.22 Tension Pin 5mm TP0518 3
4.23 Tailstock Door Knob 5569042 1
4.24 External Circlip 12mm EC12 1
4.25 Tailstock Door Magnet 5569045 2
4.26 Door Magnet screw M4 x 6 MPB0406 2
4.27 Door screw Washer 5mm FW05 1
4.28 Tailstock Door Rubber Buffer 5569046 1
4.29 Tailstock Locking Boss 5569025 1
4.30 Tailstock lock Plate 5569043 1
4.31 Tailstock lock nut M16 LN16 1
4.32 Tailstock Alignment Plate 5569032 2
4.33 Tailstock Name Plate 5569044 1
4.34 Tailstock Handwheel 6mm key 5569069 1
4.35 Bracket Flat washer 5mm FW05 2
4.36 Bracket lock nut M5 LN05 2
To Next Page
