45
128-0521-002
ITEM
NO.
DESCRIPTION SKU QTY.
5 Toolslide Assembly 5569004
5.1 Toolslide 5699022 1
5.2 Toolslide Lock Camshaft 5569036 1
5.3 Camshaft Ring 5699038 1
5.4 Toolslide Lock Boss 5699017 1
5.5 Tool slide Lock Plate 5699012 1
5.6 M6 X 10 Grub Screw SZ0610 1
5.7
Toolslide Lock Plate Mounting
Screw
CM1230 1
5.8 Cam Shaft Ring B 5699037 1
5.9 Toolrest Locking Handle 5699036 1
5.10 Cam Shaft Ring Mounting Screw C04012 2
5.11 Mounting Screws HP-16 2
5.12 Nova 12" Modular Tool Rest Bar 9028 1
5.13 Toolrest Post 1"X 5" 9025 1
5.14 Toolslide Camshaft End Cap 5569028 1
5.15 Toolslide Camshaft Grip 5569029 1
5.16 Collar Toolrest 1 Inch 27007 1
6 Bed and Stand Assembly 5569005
6.1 Main Bed Casting 5569013 1
6.2 Casted Stand 5699018 2
6.3 Stand Flat washer 12mm FW12 8
6.4 Stand Spring washer 12mm SW12 8
6.5 Stand mounting Bolts M12 x 40 C1240 8
6.6 Bed Name plate 5569058 1
6.7 Bed name plate 2 5569060 1
6.8 Name plate mounting screws RV0410/MPB0408 8
6.9 Headstock lock set 5569062 1
6.10 Feet Assembly 5569061 4
6.11 Bed end stopper plate 5569059 2
6.12 stopper plate screws M5 x 6 MPB0506 4
7 Remote Assembly 5569006
7.1 Remote Front Panel 5569051 1
7.2 Remote Controller case 5569050 1
7.3 Emergency Stop 5699016 1
7.4 Cable Gland, M12, EMC 5569081 1
7.5 Power Switch 5569052 1
7.6 Magnets 5569055 2
7.7 Magnet mounting screw M5 x 10 CM05010 2
7.8 Magnet mounting Nut M5 NN05 2
7.9 Speed knob 5569053 1
7.10 Remote Circuit Board 5569070 1
7.11 Rubber Buffer 5569054 4
7.12 Panel screws M5 x10 C05010 4
7.13 Remote Cable 5569056 1
7.14 Panel screws M3 x12 C03012 1
7.15 PCB Nut M3 NN03 1
*Note:
Item No 1.7 ASR Locking Collar and No 1.8 Nebula faceplate
ASR M33x 3.5 and 2MT Live Centre are only included in the
packages for Europe Market.
NP = Not Pictured
ITEM
NO.
DESCRIPTION SKU QTY.
11 Stand Beam Assembly 5569088
11.1 Stand Beam member 5569084 1
11.2 Stand tray set
5569085/
5569096
1
11.3 Flat washer 16mm FW16 8
11.4 Spring washer 16mm SW16 8
11.5 Mounting Bolts M16 x 40 C1640 8
11.6 Flat washer 8mm FW08 4
11.7 Mounting Button Bolts M8 x 14 SBHCS0814 4
11.8 Nylon buffer washer 8mm 5569089 4
11.9 Plastic Beam Cap 5569090 1
To Next Page
