Nova NEBULA 55600 - Mounting Faceplate or Chuck

17
128-0521-002
2.
D
ouble ended 2 Morse Taper method:
a.
Lock the Headstock at 0° by using the lock
ing
handle on the bed.
b.
Firmly i
nstall a
double ended 2MT alignment tool
on headstock
.
c.
Release the tailstock Alignment Plate
s by loosening the bolts underneath the tailstock.
d.
Slide the tailstock
firm
ly
into the other end of the alignment tool
as shown in t
h
e image below.
e.
Tighten
tailstock Alignment Plate
screws against
the
tailstock.
4.7 Mounting a Faceplate or a Chuck
The thread size of headstock Spindle is 1.25" RH (Standard version), or M33 ASR RH (Euro ASR version), depending on
your model.
1 ¼”
M33
Standard version spindle
Euro ASR version
spindle (with locking ring flange)
2MTNA Tool
