- 55 -
MAIN BODY BORE REPAIR
REPAIR OF BODY BORE BY GRINDING AND POLISHING
GRIND ROUGH EDGES OF THE ENTIRE
LENGTH OF THE SCRATCH.
(t8) POLISHING WHEEL (GRAY)
POLISH SCRATCHES IN THE O-RING AREAS (9)
TO A SMOOTH SURFACE. BLEND THIS AREA
TO THE SURROUNDING SURFACE. DO NOT
OVER POLISH!
CHECK BORE DIMENSION WITH A BORE GAUGE (t11), COMPARE WITH SPECIFICATIONS
SHOWN IN CHART ON PAGE 61.
