TouchPoint Console Installation and Setup Guide 13
Chapter 2: TPC Mounting and Setup
Hardware Requirements
You should ensure that you have all the hardware provided with the Authentication Device:
•Power supply
•Power cable
• Bypass keys(2) See
Using the Bypass Key on page 60.
• 10/100 Base-T Ethernet network cables (2)
In addition, you will need the following:
• Live Ethernet drop outlet
•USB keyboard (optional)
CAUTION: Use only the keyboard that ships with the TPC. Use of any other keyboard may result in unexpected
behavior.
Copy Control
If TPC will be used for copy control, you need a copier interface cable for your copier make and model. The copier
interface cable is shipped with each TPC, but you must order the correct cable per controlled device.
Fax Control
If TPC will be used for fax control, you will need one RJ-11 telephone or fax cable per fax device. If you ordered a fax-
enabled TPC, two RJ11 Fax cables are shipped with TPC.
Scan Control
If TPC will be used for scan device control, you will need a foreign interface cable for your scan device make and
model. The cable is available separately.
• To connect to an eCopy scan device, eCopy ScanStation version 7.1 or 8.01 is required.
• To connect to a Xerox MFP with Scan enabled, the MFP device must be configured as follows:
• SNMP protocol enabled and configured on port 161.
• SNMP GET Community Name set to public.
• Authentication Mode set to Foreign Interface Device.
• Where available, Foreign Interface Device’s Inhibit Services enabled and set to All Services.
For complete instructions on configuring scan control, refer to the "Scanning Solutions" chapter in the Equitrac
Professional Administration Guide.
