Chapter 2: TPC Mounting and Setup
14 TouchPoint Console Installation and Setup Guide
Hardware Connections
Using the labeled graphic and table on the next page for reference, complete the hardware connection procedure
outlined in
To connect the hardware on page 16.
Security
Lock
Power
Connection
USB Expansion
Ports
Device Control
Cable
Fax Port
(to fax device)
Line Port
(to wall)
External reader
port
Ethernet
Connection
(to wall)
Ethernet
Expansion Port
Serial
Port
Bypass
Keyhole
On/Off
Switch
LED Power
Indicator
