Numatic NX1K - Adjusting the Seat; Raise;Lower Brush Deck

10
Adjusting the Seat
Raise/ Lower Brush Deck
Machine Set-up Guide
Sitting in the driving position, adjust the seat forwards or backwards as necessary by using the
lever found on the left-hand side.
After preparing the oor, we are now ready to set the controls to suit the cleaning conditions.
Before any settings can be applied, ensure the brush deck is lowered.
While depressing left-hand foot pedal
press down the release lever
Gently release the foot pedal to lower the
brush deck
Depress left-hand pedal
Note: The seat is tted with a pressure sensor that disables the machine until an operator is seated.
IMPORTANT
Do not operate machine unless the operator manual has been read and fully understood.
!!
