Numatic NX1K - Fitting Dump Hose; Fitting the Hose Guide; Fitting the Floor Tool; Lowering the Floor Tool

6
Fitting the Hose Guide
Fitting Dump Hose
Break-away Floor Tool
The oor tool design incorporates a safety knock-o󰀨 feature, this allows it to safely
disengage from its mounting should it become caught on an obstruction during
forward movement.
Make sure you do not over tighten the retaining knobs.
Note: Raise oor tool before driving to the cleaning area.
The machine will not operate in reverse with the oor tool lowered.
Lower the oor tool arm by moving the release lever to the upper position (Fig.1).
Lower the oor tool.
Slide oor tool onto bracket.
Tighten retaining knobs to nger tight and
attach hose.
Raise the oor tool.
Machine Set-up Guide
Fitting the Floor Tool
1
7mm
Ret vacuum
hose to the
Floor tool when
nished.
The U-bend in the hose prevents water
spillage when the vacuum is switched o󰀨.
Ret vacuum hose to the oor tool when
nished.
Note: DO NOT
push the vacuum
hose onto the
oor tool with the
oor tool in the
raised position.
