8
Setting the Width Adjustment
Owning the TVL850 ride-on scrubber dryer is like
having 3 machines in one.
With three width-settings the operator can quickly
adapt the machine to any cleaning situation; without
the need for any tools.
The machine can be set to clean anything from a
narrow corridor to a large warehouse. The TVL850 is
a totally versatile machine.
Machine Set-up Guide
650mm 750mm 850mm
First push the side pod in, then pull
the side pod adjustment lever and
set it to one of the three width-
settings. Repeat the operation on
both sides.
