Machine Cleaning
Fuses
The clean water pump lter is located to the rear of the battery compartment, and should be checked before each use.
Lift the lter o of the cradle, unscrew the bottom and remove, taking care not to spill any liquid on to the batteries.
Rinse using clean water and ret, retting is reversal of removal.
NOTE: Any spills should be wiped up before tank is lowered.
ALWAYS ENSURE THAT THE MACHINE IS SWITCHED OFF PRIOR
TO ANY MAINTENANCE.
Located on the inside of the steering column is the machines
fuse box containing the fuses.
To the right of the fuses are the symbols identifying what the fuse
links to.
Fuses in order:
A - 2.5 Amp safety fuse
1 - 20 Amp fuse for Vacuum Motor
2 - 20 Amp fuse for Brush Motor 1
3 - 20 Amp fuse for Brush Motor
4 - 20 Amp fuse for Brush Motor
5 - 4 Amp fuse for Water Pump.
