11
Machine Set-Up
Note.
Great care must be taken to ensure that contaminants (leaves, hair, dirt, etc) are not allowed to enter the
clean-water tank during the lling process.
If using a bucket or similar, ensure it is always clean and free from debris.
Control of Substances Hazardous to Health (COSHH)
For best results use a non-foaming type of chemical, dilute to the manufacturers specication.
For further guidance on hazardous substances refer to health and safety instructions online.
Visit http://www.hse.gov.uk/ for UK information.
WHEN HANDLING AND MIXING CHEMICALS.
Always ensure that chemical manufacturer’s safety guidelines are followed.
Only use chemicals recommended for use in auto scrubber-dryers.
!
!
Fitting and lowering the Floor Tool
The oor-tool has been designed for quick tting, allowing easy squeegee blade replacement and a safety knock-off
feature if the oor-tool gets snagged, whilst in transit.
Raise the oor-tool for transit or
lower for cleaning operation using
the lifting handle tted to the back of
the machine (Fig.25).
For tting the oor-tool blades
(See Page 16).
Note:
It is easier to t the oor-tool if the weight of the machine is resting on the brush. Ensure the brush is tted rst.
Fig.24
Fig.23
Fig.25
Fit the oor-tool and retain using the
detent pin (Fig.23).
The lifting strap is also held by a
detent pin (Fig.24).
The TTB 4055/100T is equipped with a 40 litre clean-water tank allowing large areas to be cleaning in a single ll.
Filling the clean-water tank
To ll the clean-water tank, use the 1 meter FLEXI
- FILL pipe from either a tap or hose pipe (Fig.26).
The large cap can also be unscrewed for lling
from a bucket or suitable
container.
Fill the clean-water tank to a maximum of 40 litres,
including cleaning chemicals if required.
Follow chemical manufacturing guide lines.
The clear dump hose at the rear of the machine can be used to see the level of the clean water.
Fig.26
