3
Machine Overview
1
4 5
6
7
8
2
3
12
14
15
16
17
18
19
20
21
13
1. Fuse
2. Operator control panel ( see page 4 )
3. Emergency Stop
4. Separator
5. Waste-water tank
6. Clean-water tank
7. Brush deck
8. Clean-water lter
9. Free wheel lever
10. Rear moving wheels
11. Clean Water On / Off tap
12. Floor-tool vacuum hose
13. Vacuum hose
14. Top tank (waste water) drainage hose
15. Clean-water ller cap and hose
16. Clean-water level indicator / Drainage Hose
17. Floor-tool lifting lever.
18. Hour Meter
19. Isolator Key
20. Floor-tool retaining knobs
21. Squeegee blades
22. Deck Locking Mechanism
2
34
5
6
7
8
9
10
11
14
16
20
22
