17
Machine Charging
To ensure your machine remains at its maximum efciency and prolong your battery life, please follow
the simple steps below:
Under normal daily usage:
Recharge batteries after each use, regardless of
machine operation time.
Connect the charger unit to the
battery (Fig.49). and plug the charger into a suitable
power supply (Fig.50).
Fig.50
Recharge the machine fully after its last use.
Do not leave the machine in a discharged state.
Fig.49
The battery meter displays the charge level of the batteries; when fully charged,
all meter lights are illuminated.
As the machine is used and the batteries are discharged, the meter lights will go out from
top to bottom.
If the battery-charge level is allowed to discharge to the point that only one red light remains
illuminated, the operator should either replace or charge the battery.
The battery supplied with the TTB 4055/100T allows for a run time of 145 mins approx (Hi
Mode), when fully charged.
The battery pack must be fully discharged and recharged over a few cycles and brushes
need to be worn in to achieve maximum efciency.
Charge time is approximately 8 hours for the TTB Range
Spare replacement batteries are available from your supplier.
Remove the top tank to view the charging light panel
located on the pump housing plate.
Once fully charged, disconnect the charging lead from both the power supply and the machine.
Viewing panel for charging-light sequence (Fig.51).
(See page 18) for charging light sequence.
Battery Care
Viewing Panel
Fig.51
