14
Moving the machine
Free Wheel / Transit Mode
The TTB 4055/100T has a free wheel mode enabling the machine to be moved even when the battery has reached a
low level.
Move the Free Wheel Lever tted to
the left hand side of the
machine to the LOWER position to
enable the machine to be moved
WITHOUT battery power (Fig.31).
Fig.31
Move the Free Wheel lever to the
UPPER to enable the drive
mechanism to be engaged (Fig.32).
Fig.33
Fig.34
Hold down either trigger, to make the machine move (Fig.33).
Pressing either of the moving levers allows the machine to move faster.
Direction is controlled using the direction switch tted to the left side of the
handle (Fig.34).
Fig.35
Fig.32
The speed is controlled by the speed control knob tted to the right hand side
of the handle (Fig.35).
Fig.36
By pressing the emergency button Stops the machine and all its functions.
