9
6
Fit the Brush / Pad (Fig.9).
Push in the deck
locking pin (Fig.10)
and rotate the
brush deck into
the operating
position (Fig.11).
Fig.9
7
Turn on the clean water tap
(Fig.12).
8
To start: hold either trigger and
press the yellow start button once
to start the machine. (Fig.13).
Brush, vacuum and water settings
can be controlled from the control
panel (See Page 13).
Fill the clean-water to a Max of 40 litres (see page 10)
For operation and cleaning controls (see page 14)
Fig.12 Fig.13
Fig.10
Fig.11
9
Fig.14
10
Fig.15
Hold down either trigger to make the machine move.
For a speed boost when moving the machine press the grey thumb levers
down (Fig.14).
Located on the left side of the machine is the Free Wheel lever.
To disengage the brake / drive mechanism, pull the lever out and move it to
the lower hole position (Fig.17).
This allows the machine to be moved in free wheel mode, for more
information (see page 14).
Note:
When the machine is in free wheel mode the brake has been disengaged,
avoid slopes.
11
Direction is controlled using the
direction switch tted to the left side
of the handle (Fig.15).
The speed is controlled by the
speed control knob tted to the right
hand side of the handle (Fig.16).
Fig.16
Fig.17
