Maintaining and Servicing the NVIDIA DGX-1
www.nvidia.com
NVIDIA DGX-1 DU-08033-001 _v13.1|53
5.4.Updating the BMC
You can update the BMC remotely using the IPMI port. Applications can be left running.
Power must be left on.
1.
Obtain the BMC image.
a) Log on to NVIDIA Enterprise Services (https://nvid.nvidia.com/enterpriselogin/)
and click the Announcements tab to locate the DGX-1 software image archive.
b) Download the image file.
2.
Open a Java-enabled web browser within your LAN and go to http://<IPMI IP
address>/, then log in to the BMC.
Use Firefox or Internet Explorer. Google Chrome is not officially supported by the
BMC.
3.
If you’re using DHCP and choose not to preserve the network configuration, then
obtain the MAC address for the BMC.
If the BMC is connected to a network via DHCP, the IP address could change after
the update. Follow these substeps to obtain the MAC address in order to connect to
the BMC after the update, in case the IP address changes. You can skip these steps if
a static IP is used.
a)
From the top menu, click Configuration and then select Network.
b) Note the MAC address.
4.
From the top menu, click Firmware Update and then select Firmware Update from
the drop-down menu.
5.
Click Enter Preserve Configuration, then set the IPMI Preserve Status to Preserve
and all others to Overwrite.
To Next Page
