NVIDIA Jetson TX2/TX2i OEM Product Design Guide
JETSON TX2/TX2i OEM PRODUCT | DESIGN GUIDE | 20180618 39
Figure 21: DSI Dual Link Connections
Jetson TX2/TX2i
Tegra
DSI/CSI
DSI_A_CLK_P
DSI_A_CLK_N
DSI_A_D0_P
DSI_A_D0_N
DSI_A_D1_P
DSI_A_D1_N
Display
Connector (DSI)
A_D0P
A_D0N
A_D1P
A_D1N
A_D2P
A_D2N
A_D3P
A_D3N
A_CLKP
A_CLKN
B_D0P
B_D0N
B_D1P
B_D1N
B_D2P
B_D2N
B_D3P
B_D3N
B_CLKP
B_CLKN
EMI/ESD
G33
G34
F34
F35
C34
C35
E32
E33
G30
G31
F31
F32
H32
H33
D33
D34
H29
H30
D30
D31
C31
C32
E29
E30
DSI0_CK+
DSI0_CK
DSI0_D0+
DSI0_D0
DSI0_D1+
DSI0_D1
DSI1_CK+
DSI1_CK
DSI1_D0+
DSI1_D0
DSI1_D1+
DSI1_D1
DSI2_CK+
DSI2_CK
DSI2_D0+
DSI2_D0
DSI2_D1+
DSI2_D1
DSI3_CK+
DSI3_CK
DSI3_D0+
DSI3_D0
DSI3_D1+
DSI3_D1
4-Lane
4-Lane
Each 4-lane
interface can go to
a separate display,
or both can go to a
single display.
DSI_B_CLK_P
DSI_B_CLK_N
DSI_B_D0_P
DSI_B_D0_N
DSI_B_D1_P
DSI_B_D1_N
DSI_C_CLK_P
DSI_C_CLK_N
DSI_C_D0_P
DSI_C_D0_N
DSI_C_D1_P
DSI_C_D1_N
DSI_D_CLK_P
DSI_D_CLK_N
DSI_D_D0_P
DSI_D_D0_N
DSI_D_D1_P
DSI_D_D1_N
Note:
If EMI/ESD devices are necessary, they must be tuned to minimize impact to signal quality, which must meet the DSI spec.
requirements for the frequencies supported by the design.
Figure 22: DSI Split Link Connections
Jetson TX2/TX2i
Tegra
DSI/CSI
DSI_A_CLK_P
DSI_A_CLK_N
DSI_A_D0_P
DSI_A_D0_N
DSI_A_D1_P
DSI_A_D1_N
Display
Connector (DSI)
G33
G34
F34
F35
C34
C35
E32
E33
G30
G31
F31
F32
H32
H33
D33
D34
H29
H30
D30
D31
C31
C32
E29
E30
DSI0_CK+
DSI0_CK
DSI0_D0+
DSI0_D0
DSI0_D1+
DSI0_D1
DSI1_CK+
DSI1_CK
DSI1_D0+
DSI1_D0
DSI1_D1+
DSI1_D1
DSI2_CK+
DSI2_CK
DSI2_D0+
DSI2_D0
DSI2_D1+
DSI2_D1
DSI3_CK+
DSI3_CK
DSI3_D0+
DSI3_D0
DSI3_D1+
DSI3_D1
1-2
Lanes
DSI_B_CLK_P
DSI_B_CLK_N
DSI_B_D0_P
DSI_B_D0_N
DSI_B_D1_P
DSI_B_D1_N
DSI_C_CLK_P
DSI_C_CLK_N
DSI_C_D0_P
DSI_C_D0_N
DSI_C_D1_P
DSI_C_D1_N
DSI_D_CLK_P
DSI_D_CLK_N
DSI_D_D0_P
DSI_D_D0_N
DSI_D_D1_P
DSI_D_D1_N
EMI/ESD
CLK_P
CLK_N
D0_P
D0_N
D1_P
D1_N
1-2
Lanes
CLK_P
CLK_N
D0_P
D0_N
D1_P
D1_N
1-2
Lanes
CLK_P
CLK_N
D0_P
D0_N
D1_P
D1_N
1-2
Lanes
CLK_P
CLK_N
D0_P
D0_N
D1_P
D1_N

Nvidia JETSON TX2 Specifications

General

Storage	32 GB eMMC 5.1
Operating System	Linux for Tegra
GPU	NVIDIA Pascal architecture with 256 CUDA cores
Memory	8 GB LPDDR4
Connectivity	802.11ac WLAN, Bluetooth
Video Decode	4K @ 60 fps (HEVC), 4K @ 60 fps (H.264)
Power	7.5W | 15W
Camera	Up to 6 cameras (CSI)
USB	USB 3.0
Others	CAN, UART, SPI, I2C, GPIOs
CPU	Dual Denver 2 64-Bit CPUs + Quad ARM A57 CPUs
