NVIDIA Jetson TX2/TX2i OEM Product Design Guide
JETSON TX2/TX2i OEM PRODUCT | DESIGN GUIDE | 20180618 79
Internal pull-down to GND
Internal pull-down to GND
Internal pull-down to GND
Internal pull-down to GND
Internal pull-down to GND
External 10kpull-up to 3.8V
External 10kpull-up to 3.3V
Internal Pull Up to 1.8V near Tegra & PMIC
internal Pull-up to 5.0V on other side of
diodes (module pin side)
BAT54CW Schottky barrier diodes
External pull-up to 1.8V
External 100pull-up to 1.8V near Tegra
(module pin side) & external pull-up
to 1.8V on the other side of a diode
External pull-up to 1.8V
External 4.7k pull-up to 5V & Internal
PMIC pull-up to 5.0V once FET is enabled
by VDD_IN on & VIN_PWR_BAD# inactive.
External 100K pull-down to GND
External 100K pull-down to GND & 0.1uF
capacitor to GND
External 100K pull-down to GND
Carrier Board Signal Terminations
(To be implemented on the carrier board for interfaces that are used)
0.1uF capacitors if directly connected
0.1uF capacitors directly connected
0.1uF capacitors if directly connected
