Board Interface Connector
MPC5777C EVB User Guide, Rev. 1
26 NXP Semiconductors
Table 17: Test points – 416 daughter card
Signal
TP name
Shape
Description
MB PL11
TP3
Pad
Motherboard connection PL11
MB PL13
TP4
Pad
Motherboard connection PL13
MB PL15
TP5
Pad
Motherboard connection PL15
MB PJ5
TP6
Pad
Motherboard connection PJ5
MB PL9
TP7
Pad
Motherboard connection PL9
MB PJ7
TP8
Pad
Motherboard connection PJ7
MB PD7
TP9
Pad
Motherboard connection PD7
MB PF13
TP10
Pad
Motherboard connection PF13
MB PD6
TP11
Pad
Motherboard connection PD6
5.0V_LR
TP12
Hook
5V linear regulator output
RST_OUT_B
TP13
Pad
Reset out from U1
J22 26
TP14
Pad
NEXUS connection J22 26
J22 28
TP15
Pad
NEXUS connection J22 28
J22 32
TP16
Pad
NEXUS connection J22 32
J22 34
TP17
Pad
NEXUS connection J22 34
J22 38
TP18
Pad
NEXUS connection J22 38
J22 40
TP19
Pad
NEXUS connection J22 40
J31 8
TP20
Pad
JTAG connection J31 8
MB PA8
TP21
Pad
Motherboard connection PA8
MB PA14
TP22
Pad
Motherboard connection PA14
MB PA6
TP23
Pad
Motherboard connection PA6
MB PA5
TP24
Pad
Motherboard connection PA5
MB PA7
TP25
Pad
Motherboard connection PA7
MB PA9
TP26
Pad
Motherboard connection PA9
SBC_5V
TP27
Pad
SBC_5V
GND
GT1 to GT11
Hook
Ground Reference
5.0V_SR
JP1
Pin
5.0V Switching Regulator
GND
JP2
Pin
Ground Reference
3.3V_SR
JP3
Pin
3.3V Switching Regulator
5.0V_SR
JP4
Pin
5.0V Switching Regulator
1.25V_SR
JP5
Pin
1.25V Switching Regulator
GND
JP6
Pin
Ground Reference
3.3V_SR
JP8
Pin
3.3V Switching Regulator
