OAT A
STORAGE
Save It
Press the RECORD switch on the tape recorder. You should now hear a steady tone
through the MIXED OUTPUTS of the DX. The volume of the tone is controlled by the
Metronome control.
Press the CASSETTE SAVE button on the DX. After the SAVE button is pressed
, seven
seconds of the steady "
leader
" tone will be sent out followed by the actual memory
information. The SAVE button will be lit during the leader tone and then flash as each
sequence is transferred. After all of the memory information has been transferred
, the
SAVE button light wil go out
, the DX wil "
bep;' and the
display will read "
CASS"
once again.
It is very important to CHECK a tape after recording. See '
:Check To Be Sure;' below.
Check
To Be Sure
The CHECK function of the Cassette Intertace chec!,s a t
pe for valid data without
actually transferring the data into the DX'
s memory. A tape should always be checked
after recording.
Press the PLAY switch on the tape recorder. You wil now be able to monitor the tape
through the MIXED OUTPUTS of the DX.
As soon as the "
leader
" tone is heard, press the CASSETTE CHECK button on the
DX. At least three seconds of the "
'eader
" tone must come between pressing CHECK
and the rough sound of the memory information. When the leader tone is detected.
the CHECK light will go out
, and then wil fiash as each sequence is loaded. When the
data has finished
. the DX will "
beep
" and "
CASS" wil reappear on the display.
If an error is detected
, the DX wil "
beep
" and the display will read "
Err:' See
ERRORS:' below.
. NOTE: Once the
leader tone has started the cassette interface must complete its
cycle. The only way to stop it is to turn the OX off and then on again.
Load In
Press the PLAY switch on the tape recorder. You wil now be able to monitor the tape
through the MIXED OUTPUTS of the DX.
As soon as the "
leader
" tone is heard
, press the LOAD ALL button on the
X. At least
three seconds of the "
leader
" tone must come between preSing LOAD ALL and the
rough sound of the memory information. When the leader tone is detected
, the LOAD
ALL light will go out. and then will flash as each sequence is loaded. When the data
has finished
, the DX will "
beep
" and "
CASS" will reappear on the display.
If an error is detected
, the OX will "
beep
" and the
lay
wil read "
Err:' See
ERRORS;' below.
REMEMBER: The DX will not LOAD if the MEMORY PROTECT switch on the rear
panel is ON.
One At A
Time
The cassette format of the OX codes the
locaon of each Sequence and Song, which
allows an individual sequence or Song to be loaded from a tape. The
casstte inter-
face does not write an individual sequence onto the tape, but can read a single
sequence from the entire cassette.
Loading a single Sequence or Song is the
sae as
loading aU of the data except that
you press LOAD ONE. The left side of the display will show the sequence to be loaded
from tape. Use the keypad to enter the desired Sequence number. To load from a
Song, press
SONG button and then enter the desired Song number. Then press
LOAD ONE again. The right side of the display will now show the destination for the
tape sequence. Use the keypad to enter the desired Sequence number. Press LOAD
ONE again
, and the display will go dark and the DX wil wait
tor
tape data.
REMEMBER: Loading a Song loads only the list of sequences contained within the
Song, not Ihe actual sequence data.
