Page 74
Instruction Manual Easygraph
10 Disposal
Have the packaging disposed of as
recyclable waste.
When the device has reached the
end of its service life it has to be
disposed of properly:
The metal parts of the device
should go to scrap yard.
Plastic components, electrical components and
circuit boards should be disposed of as scrap
electronics.
Batteries should be disposed of as special waste.
Materials should be disposed of according to the
laws of your country.
Please use the services of suitable waste disposal
companies.
Ask your town or municipal administration for
information about local waste disposal companies.
11 Appendix
11.1.1 Technical Data
Easygraph
Measurement range 3 to 38 mm
9 to 99 D
Accuracy ±0,1 D
Reproducibility ±0,1 D
Number of Rings 22
Working distance 40 mm
Evaluated data points 22,000
Maße HxWxD 214x116x103 mm
Weight 0,63 kg
Plug-in power supply unit
Main connection 100-240 VAC, 50-60 Hz
Power consumption 5 W
Classification according to IEC Norm No. 601 - 1
Type of protection
against electric shock: Safety class II
Degree of protection
against electric shock: Type B
Degree of waterproofing IP 20
MPG Classification 1
Operating conditions
Temperature +10°C to +40° C
Humidity 30% to 75%
Air pressure 700 hPa to 1060 hPa
Transport- and storage conditions (IEC 601-1)
Ambient temperature - 40° C to +70° C
Relative humidity 10% to 100%
including condensation
Air pressure 500 hPa to 1060 hPa
11.1.2 Minimum PC requirements
Pentium 233
Windows 98SE, ME, 2000, XP
128 MB RAM
VGA 800*600 Pixel
USB-Port
