OHAUS CD-31 - Service Information; Replacement Parts; Accessories40; Technical Data

45
CD Indicators
5.5 Accessories
Description Ohaus Part No.
Adjustable Column 80250632
Wall Mounting Bracket 80250633
Scale Base Mounting Plate 80250634
RS232 Interface Cable/Printer 80500432
RS232 Interface Cable/PC 25 Pin 80500431
RS232 Interface Cable/PC 9 Pin 80500433
Printer AS142
5.6 Technical Data
Standard Equipment of CD-31 and CD-33 Indicators
• Indicator power input 9 V dc, 0.5 A
Materials
• Housing GE C6200 Cycoloy plastic.
• Keypad/display overlay polyester
Ambient conditions
The technical data are valid under the following ambient
conditions:
• Operating temperature -10°C to 45°C/14°F to113°F
• Storage temperature -40°C to 70°C/-40°F to158°F
• Relative humidity 10%.......95%, noncondensing
• Height above sea level up to 4000m
5.3 Service Information
If the Troubleshooting section does not resolve or describe your problem, you will need to contact an authorized Ohaus
Service Agent. For Service assistance in the United States, please call Aftermarket, Ohaus Corporation toll-free at
(800) 526-0659. An Ohaus Product Service Specialist will be available to help you.
5.4 Replacement parts
Description Ohaus Part No.
AC Adapter North America, 100-132 V ac, 60 Hz 80500435
AC Adapter Continental Europe, 196-253 V ac, 50 Hz 80500436
AC Adapter UK, 196-264 V ac, 50 Hz 80500437
This product is intended to be supplied by a UL Listed Direct-Plug-In Power unit marked "Class 2" and rated 9V dc, 500mA.
MODELMODEL
MODELMODEL
MODEL
CD-31 CD-31
CD-31 CD-31
CD-31
CD-33 CD-33
CD-33 CD-33
CD-33
Capa city up to 199,999 ( Lb o r Kg )
G r aduation lb / kg 0.0005 - 100
Displayed Resolution 1:10,000 LFT o r 1:50,000 ( Non LFT )
Weighing m odes lb, kg, g
Functions weighing, pa r ts counting, ani m al weighing, pe r cent, checkweighing
Ove r r ange capacity Max capacit y + 5 divisions
Stabilizati on ti m e 1 to 4 seconds, depends on fi lte r selection
Auto-ze r o t r acking c aptu r e r ange OFF, 0.5, 1, o r 3 divisions
Ze r oing r ange 2%, 18%, o r 100% o f capacity
Inte r nal r esolution 1:400,000
Span calib r ation 10 to 100% of capacity
Load cell excitation voltage 5V dc
Load cell input sensitivi ty 2 o r 3 m V / V
Load cell d r ive 4 x 350 oh m cells
Display LCD 2 line; weight and p r o m pt m essage
Powe r AC Adapte r only
Keyboa r d 12 function keys 12 function + 11 nu m e r ic keys
Ti m e and Date yes
Ove r a ll di m ensions ( WxDxH ) in mm 254 x 19.68 x 7.92
Net weight 0.65kg
Shipping weight 0.95kg
Protection
• Not protected against dust and water.
• Installation category: Class III
