Oki B4100 Maintenance Manual

42640901TH Rev.1 13 /
Oki Data CONFIDENTIAL
[Service Tools]
The tools required for field replacement of printed circuit boards, assemblies and units are listed in Table
2-1.
Table 2-1 Service Tools
No. Q’ ty Application RemarksService Tools
1
2
3
4
5
6
7
8
1
1
1
1
1
1
1
1
2~2.5 mm screws
3~5 mm screws
Cleans LED head
No. 1-100 Philips screwdriver
No. 2-100 Philips screwdriver
No. 3-100 screwdriver
No. 5-200 screwdriver
Digital multimeter
Pliers
Handy cleaner
LED Head cleaner

Oki B4100 Specifications

Performance

print speed	19 pages per minute
CPU	200 MHz
time to first page	6.0 seconds
print resolution	1200 x 600 dpi
duty cycle	15, 000 pages per month

Memory

standard RAM	8 MB
maximum RAM	8 MB

Paper Handling

standard paper input	250-sheet Letter/Legal/Universal tray
paper size minimum	3.4" x 5.5"
paper size maximum	8.5" x 14"

Weight and Dimensions

size (WxDxH)	14" x 15.6" x 7.9"
size (WxDxH in cm)	35.5 cm x 39.5 cm x 20 cm
weight	22 lb. (10.0 kg)
