42640901TH Rev.1 68 /
Oki Data CONFIDENTIAL
6.2 PCB Layout and Connector Signal List
(1) Main Control Board (GRG-5, 7 PCB)
LED Head
Printer front side
Printer front side
Contact face
Contact face
1– 26
6 – 1
Operator panel
Printer front side
