7. TROUBLESHOOTING PROCEDURE
7.7 Paper cassette switches versus Paper size correspondence table
Bit Number Dial Indication Size (OEL) Dial Indication Size (ODA)
1 2 3 4 T
RAY1 TRAY2/3 TRAY1 TRAY2/3
H H H H No cassette No cassette No cassette No cassette
L L L L A4 A4 A4 A4
H H L L A6 SEF A4 SEF A4 SEF
L H L L A5 SEF A5 SEF A5 SEF A5 SEF
L H H L LTR LEF LTR LEF LTR LEF LTR LEF
H H H L Tabloid Tabloid LTR SEF LTR SEF
H L H L B5 LEF B5 LEF Tabloid Tabloid
H L H H B4 B4 LEGAL LEGAL
L L L H A4 SEF A4 SEF EXEC EXEC
L L H L A3 A3 A3 A3
L L H H Reserved Reserved Reserved Reserved
L H L H Reserved Reserved Reserved Reserved
H H L H Reserved Reserved Reserved Reserved
H L L H Reserved Reserved Reserved Reserved
L H H H Reserved Reserved Reserved Reserved
H L L L Reserved Reserved Reserved Reserved
Press of SW: L
