Oki C830 - Left Side Cover

44015503TH Rev. 1
66 /
Oki Data CONFIDENTIAL
4. REPLACEMENT OF PARTS
4.2.3 Left side cover
(1) Open the top cover.
(2) Open the multi-purpose tray.
(3) Open the front cover.
(4) Remove the screw (silver-colored)
to detach the left side cover (tool number 1).
Front cover
Multi-purpose tray
Top cover
