Oki C830 - Page 72

44015503TH Rev. 1
71 /
Oki Data CONFIDENTIAL
4. REPLACEMENT OF PARTS
(7) Remove the four screws (silver-colored) to detach the image drum motor (tool
number 1).
(5) Remove the rear cover Assy. (see section 4.2.5).
(6) Remove the five screws (silver-colored)
to detach the main controller PCB .
