Oki C830 - Hard Disk Drive (C821 and C830)

44015503TH Rev. 1
86 /
Oki Data CONFIDENTIAL
4. REPLACEMENT OF PARTS
(5) Remove the screw (silver-colored)
to remove the fuser sensor Assy. (tool
number 1).
(4) Remove the four screws (silver-colored) to detach the contact Assy. .
