4. REPLACEMENT OF PARTS
(6) Remove the four screws (silver-colored)
to remove the base plate . (7) Remove the four screws (silver-colored) to remove the plate beam .
(8) Remove the two screws (silver-colored)
to remove the plate-beam-rear . The
side L Assy. and the side R Assy. become detached.
