- 121 -
5. Management / Setting the Printer
14
Turn off the machine after this machine becomes online.
15
Remove the LAN cable from the machine.
16
Go to "Connecting the Machine to the Authentication Switch".
Setting by Using PEAP
This section describes how to set PEAP, which is an EAP authentication type.
1
Open the Web page of this machine.
Open the Web Page of This Machine
2
Log in as the administrator.
3
Select [Admin Setup].
4
Select [Network] > [IEEE802.1X].
5
Select [Enable] from [IEEE802.1X].
6
Select [PEAP] from [EAP Type].
7
Enter a user name in [EAP User].
8
Enter a password in [EAP Password].
9
Select [Authenticate Server], and then click [Import].
10
Enter the file name of the CA certificate, and then click [OK].
Specify the certificate of the certificate authority (CA) to be used when authenticating
RADIUS server. You can import a PEM, DER, and PKCS#7 file.
11
Click [Submit].
The new settings take effect when the network function of this machine restarts.
12
Turn off the machine after this machine becomes online.
13
Remove the LAN cable from the machine.
14
Go to "Connecting the Machine to the Authentication Switch".
Connecting the Machine to the Authentication Switch
1
Check that the machine is turned off.
2
Connect the LAN cable to the network interface connector of the machine.
3
Connect the other side of LAN cable to the authentication port of an
authentication switch.
4
Turn on the machine.
5
Set the IP address of the machine, etc.
