Oki C9650dn Network And Configuration Guide

Using adminmanager standard setup > 42
> Setup by HTTP
Launches the default browser in your environment to
access the selected printer’s web page.
> Setup by TELNET
Launches the TELNET application in your environment to
access the selected printer’s TELNET port.
> Reset
Resets the selected network interface card.
> Test Print
Prints the network summary details (see page 11).
> IP Address Setup
Sets the static IP address of the network interface card
manually. If you only use TCP/IP and the print server has
not yet been configured, occasionally it may not be
displayed on AdminManager. You can configure the IP
address of the print server by this function.
(a) Enter the Ethernet Address (MAC Address) and the
IP Address, then click OK.
(b) AdminManager asks whether you want to initialise
the network interface card or not. Select Yes.
NOTE
The TELNET application is not included as part of the print
server package. Install the TELNET package on to your
system. For further information, see your Windows manual.
NOTE
The Ethernet (MAC) Address is displayed under “General
Information” on the network summary printout (see
page 11).
NOTE
Even if you select No here, the IP address that you set can be
used after turning the printer OFF and ON. The requirement
to turn your printer OFF and ON is dependent on the network
interface card.

Oki C9650dn Specifications

Performance

print speed color	36 ppm
print speed mono	40 ppm
time to first page color	10.5 sec
time to first page mono	9 sec
warm-up time	85 sec
resolution	1200 x 600 dpi

Memory

standard RAM	512 MB
maximum RAM	1, 024 MB
flash memory	4 MB
hard disk drive	40 GB

Power

power consumption operating typical	780W
power consumption peak	<1500W
power consumption standby	200W
power consumption power save	33W

Weight and Dimensions

size	23.6" x 24.6" x 18.5"
weight	167.5 lb
weight with consumables	76.0 kg
