Oki MC160MFP Maintenance Manual

44292401TH Rev.1
128 /
Oki Data CONFIDENTIAL
ADJUSTMENT/SETTING
14.4.8 FLICKER
14.4.9 TOP ADJUSTMENT
14.4.10 LEFT ADJ. (FRONT)
14.4.11 LEFT ADJ. (BACK)
Function
• Eliminates flickers of a room fluorescent light when it occurs due to power source use
environment or similar reason.
Use
• Use when the fluorescent light flickers due to power source use environment or similar
reason.
Setting/
procedure
• The default setting is 0.
“0”: Flicker control is determined according to an area code.
1: Flicker control is always on.
2: Flicker control is always off.
Function • Adjusts the top margin of media for single-sided printing.
Use
• To correct a misaligned print image.
PLAIN PAPER : Adjust the head margin of plain paper.
THICK : Adjust the head margin of thick paper.
ENVELOPE : Adjust the head margin of envelope.
Setting
/procedure
1. Select [TOP ADJUSTMENT] and press the Select key.
2. Select desired paper type and press the Select key.
3. Select desired adjustment amount with the up keyS/down keyT and press the Select
key.
-15 to +15 (1 step: 0.21 mm)
Function • Adjusts the left margin of media for single-sided printing.
Use
• To correct a misaligned print image.
TRAY 1: Adjust the left margin of media fed from tray 1 (manual tray.)
TRAY 2: Adjust the left margin of media fed from tray 2.
Setting
/procedure
1. Select [LEFT ADJ. (FRONT)] and press the Select key.
2. Select desired tray and press the Select key.
3. Select desired adjustment amount with the up keyS/down keyT and press the Select
key.
-15 to +15 (1 step: 0.21 mm)
Function • Adjusts the left margin of media for double-sided printing.
Use
• To correct a misaligned print image.
TRAY 1: Adjust the left margin of duplex print media fed from tray 1 (manual tray.)
TRAY 2: Adjust the left margin of duplex print media fed from tray 2.
Setting
/procedure
1. Select [LEFT ADJ. (BACK)] and press the Select key.
2. Select desired tray and press the Select key.
3. Select desired adjustment amount with the up keyS/down keyT and press the
Select key.
-15 to +15 (1 step: 0.21 mm)
14.4.12 TRANSFER POWER
A. SIMPLEX PASS
B. DUPLEX PASS
14.4.13 IMG ADJ PARAM
Functions • Adjust the 2nd image transfer output (ATVC) on the single-sided pages for each
media type.
Use • To use when the transfer failure at the trailing edge occurs.
Adjustment
Range
• The default setting is 0.
-8 ~ +7
Adjustment
Instructions
To increase the ATVC value (in the direction of a foggier image),
decrease the setting value.
To decrease the ATVC value (in the direction of a less foggy image),
increase the setting value.
Setting/
Procedure
1. Select [TRANSFER POWER] and press the Select key.
2. Select [SIMPLEX PASS] and press the Select key.
3. Select desired media type with the up keyS/down keyT and press the Select key.
4. Select desired setting value with the up keyS/down keyT and press the Select key.
Functions • Adjust the 2nd image transfer output (ATVC) on the duplexed pages for each media
type.
Use • To use when the transfer failure at the trailing edge occurs.
Adjustment
Range
• The default setting is 0.
-8 ~ +7
Adjustment
Instructions
To increase the ATVC value (in the direction of a foggier image),
decrease the setting value.
To decrease the ATVC value (in the direction of a less foggy image),
increase the setting value.
Setting/
Procedure
1. Select [TRANSFER POWER] and press the Select key.
2. Select [DUPLEX PASS] and press the Select key.
3. Select desired media type with the up keyS/down keyT and press the Select key.
4. Select desired setting value with the up keyS/down keyT and press the Select key.
Function • Adjusts the printer in case of an image quality problem (uneven density)
Use • To correct image quality problems (uneven density) due to the printer being operated
at a high altitude.
Setting
/procedure
• The default setting is 0.
“0”: 0 V
1: -100 V
2: -200 V
3: -300 V
NOTE
• When the setting has been changed, be sure to run a [CALIBRATION] process.
See P.105
13.4.13 IMG ADJ PARAM
13.4.12 TRANSFER POWER
13.4.9 TOP ADJUSTMENT
13.4.10 LEFT ADJ. (FRONT)
13.4.11 LEFT ADJ. (BACK)
13.4.8 FLICKER
