Oki MC160MFP Maintenance Manual

44292401TH Rev.1
130 /
Oki Data CONFIDENTIAL
ADJUSTMENT/SETTING
K. D MONO PRN
14.5.2 FAX COUNTER
14.5.3 SCAN COUNTER
14.5.4 TRAY COUNTER
14.5.5 PAPER SIZE COUNTER
14.5.6 PAPER TYPE COUNTER
Function • Displays the number of duplex monochrome printed pages produced.
Use • When checking the number of duplex monochrome printed pages produced.
Function • Displays the number of FAX printed pages produced.
Use
• When checking the number of FAX printed pages produced.
TX JOB: Counter the number of transmission job.
RX JOB: Counter the number of reception job.
Function • To display the count of the scan counter.
Use
• When checking the number of scans made.
IR: Count one when one time of IR action completed.
ADF: Count the number of sheet of ADF scanning.
Function • Displays the number of sheets of paper used for each tray.
Use
• The element to count is as follows.
TRAY1, TRAY2
Function • Displays the number of sheets of paper used for each size and type.
• A paper size counter is as follows.
A4, B5, A5, LEGAL, LETTER, OTHERS
Use
Function • Displays the number of sheets of paper used for each paper type.
• A paper type counter is as follows.
PLAIN PAPER, THICK, THICK2, ENVELOPE, LETTERHEAD, POSTCARD, LABEL
Use
14.5.7 APPLICATION COUNT.
14.5.8 SUPPLIES STATUS
14.5.9 CRU USAGE
14.5.10 JAM COUNTER
14.5.11 TROUBLE COUNTER
Function
• To display the count of the number of sheets of paper used for each of different applica-
tions.
Use
• When checking the number of sheets of paper used for each of different applications.
COPY PRINT: Number of copies made
FAX RX PRN.: Number of printed pages received by Fax
REPORT PRN.: Number of printed report pages
PC PRINT: Number of printed pages produced from PC
FAX TX: Number of transmitting to Fax.
MAIL TX: Number of transmitting to mail server.
SCAN TO FTP: Number of transmitting to FTP server.
SCAN TO SMB: Number of transmitting to SMB.
SCAN TO USB: Number of transmitting to USB memory.
TWAIN: Number of transmitting to PCl.
PICTBRIDGE: Number of sheets counts at the time of the completion of printing.
* This machine is not supporting PictBridge.
USB TO PRN.: Number of sheets counts at the time of the completion of USB printing.
Function • Display toner and image unit status.
C TONER: Displays the remaining amount of toner in the cyan (C) toner cartridge as a
percentage.
M TONER: Displays the remaining amount of toner in the magenta (M) toner cartridge
as a percentage.
Y TONER: Displays the remaining amount of toner in the yellow (Y) toner cartridge as a
percentage.
K TONER: Displays the remaining amount of toner in the black (K) toner cartridge as a
percentage.
I/C: Displays the remaining service life of the imaging unit as a percentage.
Use
Function • Displays the remaining life of the maintenance service parts.
Use
• To check the remaining life of the maintenance service parts.
TRANSFER BELT: Displays the remaining life of the transfer belt.
FUSER UNIT: Displays the remaining life of the fusing unit.
TRANSFER ROLLER: Displays the remaining life of the transfer roller.
DRUM UNIT: Displays the remaining life of the drum unit.
Function • Displays the number of misfeeds that have occurred.
Use
• When checking for the number of misfeeds that have occurred
PRINTER, ADF
Function • Displays the number of malfunctions detected.
Use
• When checking for the number of malfunctions detected
TOTAL: Total numbers of all malfunctions detected.
13.5.8 SUPPLIES STATUS
13.5.9 CRU USAGE
13.5.10 JAM COUNTER
13.5.11 TROUBLE COUNTER
13.5.7 APPLICATION COUNT.
13.5.2 FAX COUNTER
13.5.3 SCAN COUNTER
13.5.4 TRAY COUNTER
13.5.5 PAPER SIZE COUNTER
13.5.6 PAPER TYPE COUNTER
