ADJUSTMENT/SETTING
14.7.3 ADF FEED TEST
14.7.4 COPY ADF GLASS
14.7.5 FAX RES. COPY TEST
14.7.6 SCAN TEST
Function
• To check the paper feeding in the paper take-up/transport sections in the Automatic
Document Feeder.
Use • When a document misfeed occurs
Setting/
procedure
1. Load paper into the Automatic Document Feeder.
2. Press the Select key to begin testing paper feeding.
3. Press the Stop/Reset key to stop testing paper feeding.
Function • To check for dirt in the scanning section of the Automatic Document Feeder.
Use • If spots appear in the copies
Setting/
procedure
1. Load A4S or LetterS paper into Tray1.
2. Press the Select key to start the [COPY ADF GLASS] function.
3. Two copy samples are fed out.
4. Check that no spots appear in the copy samples.
5. Press the Stop/Reset key to stop the [COPY ADF GLASS] function.
Function • Fax resolution copy test
Use • To check whether the encoding/ decoding process is correct
Setting/
procedure
• The paper source is fixed to Tray1. (Tray cannot be changed.)
• When A4 or Letter is not loaded in Tray1, operation of printing is not performed.
Function • To check the lighting of the Exposure Lamp and the movement of the scanner.
Use • If the scanner malfunctions
Setting/
procedure
1. Press the Select key to begin the scanner test.
2. Press the Stop/Reset key to stop the scanner test.
14.8 SOFT SWITCH
NOTE
• Refer to the chapter of soft switch for the explanation of soft switch.
See P.137
14.8.1 KEY DEFINITION FOR SOFT SWITCH
14.9 REPORT
14.9.1 SERVICE DATA LIST
A0FDF3E504DA
SERVICE MODE
DISPLAY
FUNCTION
SOFT SWITCH

SOFT SWITCHA AAAAAAAAA
#01:10000000AAAAAA
A#02:00000100AAAAAA
A#03:01100001AAAAAA 
Bit No. 1 2 3 4 567 8
Key Definition
T Soft Switch Number Forward.
S Soft Switch Number Backward.
X Bit No. Forward.
W Bit No. Backward.
1 or 0 Bit No. is changed.
Select The setting value of Soft Switch Number is defined.
Function • Print service data list report and Error log history list.
Use
Service Data list includes the following items:
• SOFT SWITCH
• COMMUNICATION HISTORY & COUNTER
• ADJUST
• RX IN MEMORY
• ADMINISTRATOR PASSWORD
• MAIN RAM SIZE
• ROM ID
Error log history list includes the following items:
• Index: Index number from 0 - 9999
• Error: Error code number
• Maker: NSF frame maker code
• Tell.: Remote side or TX side telephone number for that transaction
Setting/
procedure
1. Enter the [SERVICE MODE].
2. Select [REPORT] and press the Select key.
3. Select [SERVICE DATA LIST] and press the Select key.
13.8.1 KEY DEFINITION FOR SOFT SWITCH
13.9 REPORT
13.9.1 SERVICE DATA LIST
13.8 SOFT SWITCH
NOTE
13.7.3 ADF FEED TEST
13.7.4 COPY ADF GLASS
13.7.5 FAX RES. COPY TEST
13.7.6 SCAN TEST
